Color coated aluminum sheets & coils is the surface coating of aluminum plate coloring treatment, the common fluorocarbon color-coated aluminum, polyester color-coated aluminum , widely used in aluminum plastic plates, aluminum veneer, aluminum honeycomb panels, aluminum ceiling, roof, edges and corners, easy-to-open cans, electronic products. Its performance is very stable, not easy to be corroded, the surface after special treatment can reach 30 years of quality assurance.
Inquiry
· Place of Origin:Henan, China
· Model Number:1050/1060/1100/3003/5052
· Application:Decoration, decoration
· Width:MAX 2000mm,
· Alloy Or Not: Alloy
· Grade:1000/3000/5000 series
· Surface Treatment:Coated
· Temper:O,H42,H44,H46,H48
· Tolerance:±0.02mm
· Coating Thickness: 18-25 μm
· Processing Service:Punching
· Material:Aluminum alloy
· Color:Customers’ Request
· Certification:ISO9001 ROHS TUV
· Packing:Wooden Cases
· Standard:ASTM, EN,GB/T 3880-2012
| Chemical Compositon Of Aluminum: | |||||||||||
| Grade | Chemical Composition(%) | Others | AI | ||||||||
| Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Single | Tol | 99.5 | |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | – | 0.05 | 0.03 | 0.03 | – | 99.6 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | – | 0.05 | 0.03 | 0.03 | – | 99.7 |
| 1070 | 0.2 | 0.25 | 0.04 | 0.03 | 0.03 | – | 0.04 | 0.03 | 0.03 | – | 99 |
| 1100 | 0.95 | 0.05~0.4 | 0.05 | – | – | 0.1 | – | 0.05 | 0.15 | Remains | |
| 3003 | 0.6 | 0.7 | 0.05~0.2 | 1.0~1.5 | – | – | 0.1 | – | 0.05 | 0.15 | Remains |
| 3004 | 0.3 | 0.7 | 0.25 | 1.0~1.5 | 0.8 | – | 0.25 | – | 0.05 | 0.15 | Remains |
| 3005 | 0.6 | 0.7 | 0.3 | 1.0~1.5 | 0.2~0.6 | 0.1 | 0.25 | 0.1 | 0.05 | 0.15 | Remains |
| 3105 | 0.6 | 0.7 | 0.3 | 0.3~0.8 | 0.2~0.8 | 0.2 | 0.4 | 0.1 | 0.05 | 0.15 | Remains |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2~2.8 | 0.15~0.35 | 0.1 | – | 0.05 | 0.15 | Remains |
| 5083 | 0.4 | 0.4 | 0.1 | 0.4~0.1 | 4.0~4.9 | 0.05~0.25 | 0.25 | 0.15 | 0.05 | 0.15 | Remains |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6~3.6 | 0.3 | 0.2 | 0.15 | 0.05 | 0.15 | Remains |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.5~1.1 | 0.1 | 0.25 | – | 0.05 | 0.15 | Remains |
| 5086 | 0.4 | 0.5 | 0.1 | 0.2~0.7 | 3.5~4.5 | 0.05~0.25 | 0.25 | 0.15 | 0.05 | 0.15 | Remains |
| 6063 | 0.2~0.6 | 0.35 | 0.1 | 0.1 | 0.45~0.9 | 0.1 | 0.1 | 0.1 | 0.05 | 0.15 | Remains |
| 6041 | 0.4~0.8 | 0.7 | 0.15~0.4 | 0.15 | 0.04~0.35 | 0.04~0.35 | 0.25 | 0.15 | 0.05 | 0.15 | Remains |
